DESCRIPTION
This MRCOOL Olympus Energy Star Series ductless mini-split heat pump and air handler system now features efficiency ratings up to 25.5 SEER. Designed to be installed by an HVAC professional, this system is effective, affordable, and Energy-Star certified. With a ton of useful functions and modes, such as sleep mode, auto swing, timer mode, and auto restart, you can customize your comfort experience to best fit your needs. Setup is a breeze thanks to the WiFi control module that also improves functionality. Youre also able to control this system with your Amazon Alexa, Google Assistant, or the SmartHVAC app.
FeaturesInstallation by a licensed professional required where applicable7-Year Compressor, 5-Year Parts and 1-Year Remote warranty when registered and when installed by a licensed professionalR-410A environmentally friendly refrigerantEnergy Star certified
SPECIFICATIONS
Condenser Dimensions |
21.85"H x 30.12"W x 11.93"D |
Condenser Weight |
63.71lbs |
Air Handler Dimensions |
11.61"H x 31.30"W x 8.86"D |
Air Handler Weight |
22.71lbs |
SEER |
Up To 25.5 |
SEER2 |
25.5 |
EER |
Up To 15 |
EER2 |
15 |
HSPF |
hspf4/hspf5: 12.2/10 |
HSPF2 |
hspf4-2/hspf5-2: 12.3/9.2 |
Cooling Capacity |
9000 BTU |
Heating Capacity |
10000 BTU |
Voltage |
208/230V |
Phase |
1 |
Cycle |
60Hz |
Max Fuse Breaker |
15 A |
Min Circuit Capacity |
0.125 |
Zone Capacity |
1 |
Refrigerant Type |
R410A |
Refrigerant Volume |
38.10 oz |
Decibal Rating |
34 dBA |
Decibal Rating Low |
23 dBA |
Decibal Rating High |
38 dBA |
Liquid Line Size |
1/4in |
Suction Line Size |
3/8in |
Compressor Motor Type |
ROTARY |
Condenser Fan Motor RPM |
800/600 |
Blower Motor RPM |
1100/850/700 |
Filter Type |
Replaceable |
Overload Protection |
yes |
Fan Only Option |
yes |
Quiet Mode |
yes |
Sleep Mode |
yes |
Auto Cool |
yes |
WiFi Compatibility |
yes |
App Compatibility |
yes |
Works with IOS |
yes |
Works with Android |
yes |
Remote Control Included |
yes |
Energy Star Compliant |
yes |
Energy Star Certified |
yes |
AHRI Certified |
yes |
Registered Warranty |
5-year Parts/7-year Compressor/1-year Remote |
Registered Parts Warranty |
5-year |
Registered Compressor Warranty |
7-year |
Registered Remote Warranty |
1-year |
Has Batteries |
yes |
Contains Electronics |
yes |
Contains Chemicals |
yes |
Contains Aerosol |
yes |
Contains Compressed Gas |
yes |
Restricted States |
GU, PR, VI |
