DESCRIPTION
There's nothing like your first high gas bill of the season to make you dread a long, cold winter. If that's the boat you're in, you need to make a change. You need to invest in a powerful, high quality, and energy efficient heater like the 95% AFUE multi-positional gas furnace by MRCOOL. Unlike a lot of other furnace models, the MRCOOL 95% AFUE furnace wastes a minimal amount of fuel. This ensures most of your dollar is spent wisely rather than wasted, and that in turn means you have to spend less of those dollars to keep your house warm all winter long. Depending on the severity of winter weather where you live, that might mean the difference between a few dozen dollars or a few hundred dollars. So don't dread winter. Instead, choose the efficient, versatile and high quality heat of the MRCOOL. It's also protected by a 20 year Heat Exchanger Warranty, and a 10-Year Registered Parts Warranty.
FeaturesMulti-speed high efficiency (constant torque) blower motorSelf diagnostics saves last 10 fault codes regardless of power interruptionStandardized widths for easy coil fit10 year registered parts warranty20 year heat exchanger warrantyAluminized steel inshot burners for smooth ignitionComplies with California's South Coast Air QualityOptional LP kitEasily removable slide out blower designConstant torque motor produces consistent airflow and even temperaturesUses up to 1/3 less energy than a fixed-speed blowerLeft or right utility connections, removable floorbase for bottom return air, zero step horizontal conversion
SPECIFICATIONS
Dimensions |
33"H x 17.5"W x 28.5"D |
Weight |
134 lbs |
AFUE |
95 |
CFM |
1215 |
Tonnage |
3 |
Heating Capacity |
66,000 BTU |
Fuel Type |
Natural Gas |
BTU Input |
66000 |
BTU Output |
64000 |
Voltage |
120 |
Phase |
1 |
Cycle |
60 |
Stage |
Single |
Max Fuse Breaker |
15 |
Min Circuit Capacity |
6.8 |
Color |
Gray |
Color Family |
Gray |
Number of Burners |
6 |
Gas Connection Size |
0.5 |
Blower Motor Type |
ECM |
Blower Motor HP |
1/2 |
Blower Motor Speeds |
4 Speed |
Blower Motor RPM |
670-1215 |
Heat Exchanger Type |
Aluminized steel primary, AL 29-4C Stainless steel |
Ignition Type |
silicon nitride ignitor |
Vent Connector |
2 inch |
LP Kit Included |
No |
LP Kit Available |
Yes |
CSA Certified |
Yes |
ISO Certified |
No |
Energy Star Compliant |
No |
Energy Star Certified |
No |
AHRI Certified |
Yes |
Registered Warranty |
10 year registered parts warranty |
Registered Heat Exchanger Warranty |
20 year heat exchanger warranty |
Base Heat Exchanger Warranty |
20 year heat exchanger warranty |
Has Batteries |
No |
Contains Electronics |
Yes |
Contains Chemicals |
No |
Contains Aerosol |
No |
Contains Compressed Gas |
No |
Proposition 65 Warning |
Yes |
Gross Depth |
32.5 |
Gross Height |
35 |
Gross Width |
23.5 |
Gross Weight |
134 lbs |
Restricted States |
No |
PRODUCT DOCUMENTATION
BrochureSpecsWarranty DocRELATED CERTIFICATES
AHRI CertificateEnergy Guide Certificates
