DESCRIPTION
A MRCOOL packaged heat pump combines high performance cooling and powerful heating in one convenient, easy-to-install system. These units are competitively priced and operate at 14 SEER efficiency. A MRCOOL packaged heat pump will be a great solution for tough air comfort problems in a suburban home, commercial office space, condominium, seaside villa, or wherever you desire. MRCOOL packaged heat pumps combine superior product quality, energy efficiency, quiet operation, and financial value. The units come standard with a high performance compressor and eco-safe, chlorine-free R-410A refrigerant. This is truly an all-in-one packaged unit that will deliver energy efficient air comfort with minimal environmental impact.
FeaturesWarranty is 10 years on all parts if registered, 5 years if not (no licensed tech required)14 SEER efficiencyDesigned for easy and convenient installationOptional electric heat availableR-410A environmentally friendly refrigerantBuilt in short cycle protection to protect the compressorOne piece "no leak" top designSloped drain for improved indoor air qualityLouvered panel coil protectionInsulation to minimize heat loss plus reduce soundBuilt in "quiet shift" operation during defrost on select modelsEfficient constant torque motor for wide airflow range
SPECIFICATIONS
Dimensions |
40.89 "H x 47.66 "W x 47.66 "D |
Weight |
379lbs |
SEER |
14 |
SEER2 |
13.4 |
EER |
11 |
EER2 |
10.6 |
COP 47 |
3.7 |
HSPF |
8 |
HSPF2 |
6.7 |
CFM |
1050 |
Tonnage |
2.5 |
Cooling Capacity |
28600 |
Heating Capacity |
27000 |
Voltage |
208/230 |
Phase |
1 |
Cycle |
60 |
Stage |
Single |
Max Fuse Breaker |
35 |
Min Circuit Capacity |
21.9 |
Color |
Gray |
Color Family |
Gray |
Rated Load |
15 |
Maximum Coverage Area |
1250 |
Refrigerant Type |
R-410A |
Refrigerant Volume |
96 |
Decibal Rating |
78 |
Min Ambient Heat |
0 |
Compressor Motor Type |
Scroll |
Condenser Fan Motor Type |
ECM |
Condenser Fan Motor HP |
1/6 |
Blower Motor Type |
ECM |
Blower Motor HP |
1/3 |
Blower Motor Speeds |
Multi-speed |
Blower Motor RPM |
530-1070 |
Filter Type |
Replacable |
Filter Size |
14x20x1 |
Metering Device |
TXV |
Auxiliary Heater Included |
No |
Auxiliary Heater Available |
Yes |
Auxiliary Heater Sizes |
5kw, 7.5kw |
UL Recognized |
No |
UL Listed |
No |
ETL Listed |
Yes |
ETL Certified |
No |
LEED Certified |
No |
ASHRAE Compliant |
No |
Energy Star Compliant |
No |
Energy Star Certified |
No |
AHRI Certified |
Yes |
Registered Warranty |
Warranty is 10 years on all parts if registered |
Base Warranty |
5 years if not (no licensed tech required) |
Has Batteries |
No |
Contains Electronics |
Yes |
Contains Chemicals |
Yes |
Contains Aerosol |
Yes |
Contains Compressed Gas |
Yes |
Proposition 65 Warning |
Yes |
Gross Depth |
48 |
Gross Height |
42.5 |
Gross Width |
48.75 |
Restricted States |
No |
Freight Class |
125 |
PRODUCT DOCUMENTATION
BrochureInstall ManualSpecsOwner ManualRemote ManualWarranty DocRELATED CERTIFICATES
AHRI CertificateEnergy Guide Certificates
