MRCOOL 24K BTU, 16 SEER, 17.5", 2 Ton R410A Downflow Cased Evaporator Coil | MCDP0024ANPA

Save $137.00
MRCOOLSKU: MCDP0024ANPA

Price:
Sale price$542.00 Regular price$679.00

Checkout Securely

Amazon American Express Apple Pay Diners Club Discover Meta Pay Google Pay Mastercard PayPal Shop Pay Visa

Your payment information is processed securely. We do not store credit card details nor have access to your credit card information.

Enjoy Free Shipping.

No Sales Tax Outside of CA.

Estimated Handling Time:

  • Product Ships within 1-3 days.

Estimated Arrival Time:

  • Please Allow 5-7 business days.

We guarantee your satisfaction:

Description

DESCRIPTION

This is a brand new 2 ton, R410A refrigerant, downflow cased Evaporator Coil. This efficient and durable coil is the solution for heat pumps and air conditioners for fast, flexible application. This Signature Series coil, when appropriately paired with a MRCOOL Signature Series condenser and gas furnace or modular blower, can achieve efficiency ratings of up to 16 SEER.


Features

  • Interlocking door assemblies and snug line sealgrommets to minimize air leakage
  • All units UL Listed and AHRI Certified
  • One of the lowest water retention drain pans in the industry to minimize mold and mildew growth
  • Heavy-gauge steel constructed cabinet for optimal support of the furnace, no need for additional bracing or structure.
  • Foil-face insulation for easy cleaning
  • All drain pans are compatible with UV lights
  • Removable Cabinet panels for easy coil service
  • Superior service access to components, withtubing located at door split and foil-face insulation
  • 10-Year Parts Limited Warranty
  • Aluminum tubing, hairpins, distributors and header tubes. Copper refrigerant connections for easy brazing to both liquid and suction lines.
  • Tubing located at door split for easy coil service or cleaning

  • SPECIFICATIONS

    Dimensions 14.5"H x 26-1/8"W x 14-1/8"D
    Weight 44lbs
    Tonnage 2
    Cooling Capacity 24000
    Color Gray
    Color Family Gray
    Refrigerant Type R-410A
    Drain Connection Size 3/4
    Lineset Included No
    Lineset Length 15ft, 25ft, 35ft, 50ft
    Max Lineset Length 50ft
    Lineset Fitting Type Sweat
    Liquid Line Size 3/8
    Suction Line Size 7/8
    UL Recognized yes
    UL Listed yes
    Energy Star Compliant no
    Energy Star Certified no
    AHRI Certified yes
    Registered Warranty Registered 10 Year Parts Warranty
    Base Warranty 5 Year Parts Warranty
    Registered Parts Warranty Registered 10 Year Parts Warranty
    Base Parts Warranty 5 Year Parts Warranty
    Contains Chemicals Yes
    Contains Aerosol Yes
    Contains Compressed Gas Yes
    Proposition 65 Warning Yes
    Gross Weight 44 lbs
    Restricted States No

    PRODUCT DOCUMENTATION

  • Brochure
  • Specs
  • Warranty Doc

  • RELATED CERTIFICATES

  • AHRI Certificate
