DESCRIPTION
The new U-shaped Window Air Conditioner is the latest technology to come from MRCOOL. With its revolutionary U-Shaped design, this Air Conditioner gives you the ability to open and close the window it is installed in. By being able to close the window, it helps create a sound barrier to keep unwanted noise outside making it incredibly quiet. The unit also features a redesigned bracket that simplifies and shortens the installation process.
Features15 BTU/H/Watt CEERThe ability to close the window the unit operates in, allows the sound of the compressor to remain outside and separate from the inside of your home.The new bracket included with this system snaps together, and can be installed in only a few steps.This unit creates a powerful current of cold air, which can be felt up to 20 feet away.Energy Star CertifiedWindow Opening Minimum Height: 13.75 in  Window Opening Minimum Width: 22in || Window Opening Maximum Width: 36inCord Length: 4.92ft
SPECIFICATIONS
Dimensions |
13.46 "H x 19.17 "W x 21.97 "D |
Weight |
58.86 lbs |
EER |
3.09 |
CFM |
161/192/265 |
Cooling Capacity |
12000 BTU |
Voltage |
115 V |
Phase |
1 |
Cycle |
60 Hz |
Max Fuse Breaker |
13.5 A |
Color |
White |
Rated Load |
12.17 A |
Maximum Coverage Area |
550 sqft |
Refrigerant Type |
R32 |
Decibal Rating Low |
42 dBA |
Decibal Rating High |
52 dBA |
Number of Speeds |
3 Speed |
Oscilation |
No |
Inverter |
DC |
Min Ambient Cool |
60.8F – 89.6F |
Compressor Motor Type |
Rotary |
Condenser Fan Motor RPM |
1272/1483/1906 |
Filter Type |
Washable |
Auxiliary Heater Available |
No |
Low Voltage Compensation |
Yes |
Overload Protection |
Yes |
Fan Only Option |
Yes |
Sleep Mode |
yes |
Auto Cool |
Yes |
WiFi Compatibility |
Yes |
App Compatibility |
Yes |
Remote Control Included |
Yes |
Energy Star Certified |
Yes |
Registered Warranty |
1 Year Limited Warranty |
Contains Electronics |
Yes |
Contains Chemicals |
Yes |
Proposition 65 Warning |
Yes |
Gross Depth |
24.29 in |
Gross Height |
17.48 in |
Gross Width |
21.14 in |
Gross Weight |
72.53 lbs |
PRODUCT DOCUMENTATION
BrochureInstall ManualSpecsRELATED CERTIFICATES
Energy Guide Certificates
